General Information
| Manufacturer | Schneider Electric SA |
| Manufacturer Part Number | E3SUPS30K3IB |
| Manufacturer Website Address | |
| Brand Name | Schneider Electric |
| Product Line | Easy UPS 3S |
| Product Name | Easy UPS 3S 30KVA 400V 3:1 UPS for Internal Batteries |
| Marketing Information | High-efficiency 3-phase UPS that features advanced product features, competitive specifications, and robust electrical design, making business continuity easy in the data center or electrical room. This is an exceptionally easy to install, operate, maintain, and service 30 kVA UPS, ideal for small and medium businesses. Includes dust filter and conformance-coated boards for harsh environments. This UPS is for internal batteries, but is supplied without batteries, so you can easily customize the battery runtime. For battery runtime details, see the runtime charts published under the Documents tab. |
| Packaged Quantity | 1 Pack |
| Product Type | Double Conversion Online UPS |
Technical Information
| Phase | Three Phase |
| Application/Usage |
|
Power Description
| Load Capacity (VA) | 30 kVA |
| Load Capacity (Watt) | 30 kW |
| Input Voltage |
|
| Input Voltage Range | 304 V AC - 477 V AC |
| Input Frequency | 65 Hz |
| Output Frequency | 60 Hz |
| Input Power Factor | 0.9 |
Interfaces/Ports
| USB (HID Compliant) Port | Yes |
Battery Information
| DC System Voltage | 198 V DC |
| Battery Characteristics | Valve-regulated |
Environmental Conditions
| Maximum Operating Temperature | 40°C |
| Maximum Operating Elevation | 1 km |
| Maximum Storage Elevation | 15.24 km |
| Storage Relative Humidity | 0% - 95% |
| Sound Emission (A-Weighted) | 63 dB(A) |
| Thermal Dissipation | 1810 BTU/h |
Physical Characteristics
| Product Color | White |
| Form Factor | Tower |
| Height | 1400 mm |
| Width | 500 mm |
| Depth | 996 mm |
| Weight (Approximate) | 185 kg |
Miscellaneous
| Package Contents |
|
| Environmentally Friendly | Yes |
| Environmental Certification |
|
Warranty
| Limited Warranty | 1 Year |
| Additional Warranty Information | 1 year on-site repair or replace with factory authorized Start-Up |
